The modern networking age has led businesses and organizations to require cutting-edge, reliable, and scalable solutions for their operational support. Cisco is one of the leading networking companies that provide a complete range of enterprise-class switches for high performance, security, and efficiency. One of these switches is the Cisco Catalyst 3850-48U-S (WS-C3850-48U-S). This article discusses the features, benefits, and technical specifications of this powerful switch, which will help you understand why this switch is the perfect fit in high-demand scenarios.
Overview of Cisco Catalyst 3850-48U-S
The Cisco Catalyst 3850-48U-S belongs to the Cisco Catalyst 3850 Series, a fully stackable series of enterprise-class switches with a powerful networking pedigree. It comes with 48 UPOE ports that deliver both data and power over the same cable, thus being ideally suited for installations requiring PoE devices such as IP phones, wireless access points, and security cameras.
This model also supports the IP Base feature set that offers advanced Layer 3 features like static routing and supports up to 1,000 VLANs. The stackable architecture allows several switches to function as one single logical device, thus offering scalability and resiliency in management.
Key Features of Cisco Catalyst 3850-48U-S
- 48 Universal PoE Ports:
- Supports up to 60W of power per port
- Ideal for powering devices like VoIP phones, IP cameras, and wireless access points
- StackWise-480 Technology:
- Allows stacking of up to 9 switches
- Provides a unified management interface
- Ensures increased bandwidth and redundancy
- Performance and Capacity:
- Switching capacity: 480 Gbps
- Forwarding rate: 68.45 Mpps (million packets per second)
- 4 x 10G SFP+ uplink interfaces for high-speed connectivity
- Advanced Security Features:
- Access Control Lists (ACLs) for traffic filtering
- IEEE 802.1X for network access control
- Secure Shell (SSH) Protocol for secure remote management
- Modular QoS (Quality of Service):
- Prioritizes critical network traffic
- Ensures seamless performance for voice and video applications
Benefits of Cisco Catalyst 3850-48U-S
- Enhanced Power Delivery: The switch supports all Universal PoE standards, delivering up to 60W per port for whatever powered device that might be used- eliminating the need for power infrastructure.
- Simplified Management: StackWise-480 means that up to nine switches can be treated as a single switch for management purposes, reducing complexity and increasing operational efficiency.
- High Availability: Redundant power supply configurations and stackable architecture provide maximum uptime and greater business continuity.
- Scalability: Supports enough VLANs and uplinks to allow the switch to adapt to the ever-growing needs of the network.
- Robust Security: Total security architecture to ensure protection of sensitive data and access of only trusted devices into the network.
Technical Specifications
- Model Number: WS-C3850-48U-S
- Ports: 48 x UPOE ports
- Uplink Interfaces: 4 x 10G SFP+
- Switching Capacity: 480 Gbps
- Forwarding Rate: 68.45 Mpps
- Stacking Support: Up to 9 switches with StackWise-480
- Power Supply: 1100W AC power supply included
- Dimensions: 1.73 x 17.5 x 17.7 inches (4.4 x 44.5 x 45 cm)
- Weight: 17.6 lbs (8 kg)
Use Cases
- Enterprise Networks-This way are the best options for large organizations that demand high-performance, scalable, and secure switching solutions.
- Data Center-Design for high-speed data transmission and traffic management with multiple 10G uplinks.
- Campus Environments-PoE covers connected devices such as IP phones and access points in wide areas.
- Retail Chains-Uses large PoE capabilities for point-of-sale systems and security surveillance.
Why Choose Cisco Catalyst 3850-48U-S?
Scorecard Award for organizations needing a high-performance switch with high PoE capabilities. Its 60W per port capacity can sustain advanced devices while offering strong security, smooth scalability, and easy management.
As an authorized dealer of Cisco products, Jazz Cyber Shield sells Cisco Catalyst 3850-48U-S including full warranty support and expert customer service. Personalized networking solutions are provided to ramp your business towards operational excellence.
Conclusion
In summation, businesses that demand sophistication in performance, scalability, and power will find the Cisco Catalyst 3850-48U-S switch to be an excellent fit. With so many advanced features and ease of management, it remains a persuasive candidate for modern network needs. For further inquiries or the procurement of Cisco Catalyst 3850-48U-S, Jazz Cyber Shield-your trusted Cisco partner.
